The roller processing equipment designed this time mainly includes automatic steel pipe cutting machines, automatic dual-end pipe drilling machines, and carbon dioxide gas shielded automatic welding machines, etc.
(1) Support Roller Pipe Cutting MachineModel: CO160
Applicable pipe diameter (outer diameter) range: Ф89, Ф108, Ф133, Ф159, Ф194, Ф219mm
Applicable pipe wall thickness range: 3~12mm
Maximum length of raw pipe material: 9000mm
Main machine center height: 1000mm
Spindle speed: 50~250r/min
Feeding speed: 0~60mm/min
Cutting length range: 180mm~2600mm
When cutting length is 800mm, the cutting length error is ±0.2mm;
when length exceeds 800mm, error reaches IT9 precision
Parallelism tolerance of the cut ends: level 9
Cutting and chamfering surface roughness: 6.3~12.5(2)
Support Roller Double-Head Automatic Welding MachineInput Power: Three-phase 380V 50Hz
Applicable welding wire: Ф1.2~1.6mm
Shielding gas flow rate: 10~25L/min
Weldable workpiece length: 300~2600mm
Weldable workpiece diameter: Ф89~Ф219
Spindle speed: 0~10rpm
Clamping cylinder stroke: 200mm
Adjustable welding torch angle: ±20°
Machine size: 5100x880x1700mm
